Product Introduction

GLS vibrating probability screen is referred to as probability screen. The running trajectory of the screen box of the probability screen is a straight line, so it is also called GLS linear probability screen. It is a new and efficient vibrating powder screening equipment. The new design concept and unique structure and screening principle make the probability screen have a very good screening effect and are suitable for use in various industries. The GLS series probability screen is Running Machinery's introduction of advanced production technology and careful research based on our company's user environment. Compared with ordinary vibrating screens, it has better screening efficiency and is now widely used in cement, mining, building materials, In industries such as chemical industry, fine screening of medium and fine particles has the best effect. The probability screen adopts a large inclination screen surface, and the inclination angle of the screen surface increases from top to bottom. Using probability theory, the screen holes are larger than the required screening particle size (1.2-2.2 times), which greatly improves the screening efficiency and production capacity.

Product Features

1. Highest applicability and production reliability.

2. High screening efficiency.

3. Large capacity.

4. Space saving and easy maintenance.

5. Quick screen replacement and low power requirements.

Application

1. Mining and minerals: Efficient grading of bulk materials like coal, ores, and crushed stones with varying particle sizes.

2. Agriculture: Sorting grains, seeds, and fertilizers based on size with high throughput.

3. Chemical industry: Screening powders and granular materials while reducing material buildup risks.

4. Construction materials: Classifying sand, gravel, and aggregates for quality control in production lines.

5. Recycling facilities: Separating mixed waste materials such as plastics, metals, and glass fragments.

6. Food processing: Sifting sugar, salt, and spices with minimal particle damage or degradation.

7. Pharmaceuticals: Ensuring uniform particle size distribution in powders and granules.

8. Power plants: Screening biomass fuels and ash residues for efficient energy production.

9. Metallurgy: Sorting metal powders, alloys, and slag in high-volume operations.

10. Ceramics and abrasives: Grading raw materials like silica and alumina for consistent product quality.

Application4

Technical Parameters

Model		Number oflayers	Sieve surface				Granularity(mm)	Power(kw)	Wibrationfrequency (1/min)	Amplitude(mm)	CAPACITY (T/h)
			Stucture	Mesh Size(mm)	Area(mm)	Tilt Angle
GLS	1236	2-5	Woven screen	~50	4.3	15~30	≤50	11*2	960	6-9	30-120
GLS	1536				5.4			3*2			30-180
GLS	2036				7.2			3.7*2			30-120
GLS	2236				7.9			3.7*2			50-120
